Converting Box Flexo Printer Slotter Die Cutter Machine
| Model | 920 | 1224 |
| Max. Speed(pcs/min) | 300 | 250 |
| Max Feeding Size(mm) | 900×2000 | 1200×2400 |
| Min Feeding Size(mm) | 260×600 | 320×600 |
| Skip Feeding (mm) | 1200×2000 | 1500×2400 |
| Max. Printing Area(mm) | 900×1960 | 1200×2360 |
| Min. Slotting Reverse knife(mm) | 240×65×240×65 | 260×65×260×65 |
| Min. Slotting Normal knife(mm) | 130×130×130×130 | 130×130×130×130 |
| Slotting Depth (mm) | 250 | 300 |
Lead Edge Feeder
Lead edge feeder
1) Lead edge feeding paper mechanism can greatly reduce clogging phenomenon in the process of feeding cardboard paper.
2) Suction fan auxiliary paper feeding, to ensure bend paperboard feeding
smoothly, the air volume can be adjusted for various sections according to the size of paperboard, ensure the maximize of the cardboard vacuum adsorption capacity, to make more accurate feeding paper.
Rotary Die-Cutter Unit Features:
A. Die Cylinder (Lower)
● Ground and chromed high quality steel
● Dynamic balanced for stable running.
● Fixing hole distance is 50mm lateral.
● Creasing height is 22.60mm.
● Wooden die thickness is 13mm.
B. Anvil Cylinder (Upper)
● Ground and chromed high quality steel
● Dynamic balanced for stable running.
● Anvil cover thickness is 10mm,width is 252mm.
● Side to side oscillation of anvil cylinder( 50mm).
● Motorized gap adjustment between anvil roll and die cylinder.
C. Self-locking System Adopted for Pulling Roll Gap.
D. Cam bearing applied for the Pull Roll working, wear reduced and run more stable.
E. Cutting Registration Adjust System
● Planetary gear system
● Cutting registration controlled by PLC and motorized, 360°adjust.
● Lateral registration controlled by PLC and motorized, range ±10mm.
F. Anvil Speed Compensating System with Dependent Motor, range ±3mm.
G. With Anvil Grinding System for Keeping Smooth.
1.CNC control system (Intelligent Control)
2.Environmental Protection and Energy Saving, use washable ink;
3.Apply to box for big household appliances such as refrigerator, air-conditioner, and heavy industrial box, such as motorbike, auto spare parts.
4.Able to print and make honeycomb box.
Our Service
Pre-Sales Service
* Inquiry and consulting support.
* View our Factory.
After-Sales Service
* Installation, training how to use the machine and technical support.
* Engineers available to service machinery overseas.
.
